Three-speed circulation pump AVANSA 32-6/180

Product detailed description

- installation length 180 mm, displacement 6 m, max. flow 55 l/min

Applicable in hot and cold non-potable water systems. The pump body is made of cast iron, cast aluminium. High-quality bipolar motor, asynchronous, does not require overload protection, has three speeds. It is controlled by a special switch mounted on the terminal block, which allows to adjust the pump according to the device characteristics.

Technical data:

• max. working pressure: up to 10 bar
• max. temperature of the pumped medium: + 110 °C
• protection class: IP44, insulation class: FH
• pump part material: cast iron / plastic
• version: 230 V
• distance between suction and discharge nozzle: 180 mm
• electric motor power: 93 / 67 / 46 W
• displacement: 6 m, max. flow: 55 l/min
• connection dimensions: 2“
