Three-speed circulation pump AVANSA 25-8/180

Product detailed description

- installation length 180 mm, delivery head 8 m, max. flow rate 115 l/min

Applicable in hot and cold non-potable water systems. The pump body is made of cast iron, cast aluminium. A high-quality bipolar motor, asynchronous, does not require overload protection, has three speeds. It is controlled by a special switch mounted on the terminal block, which allows the pump to be adjusted to the device's characteristics.

Technical data:

• max. working pressure: up to 10 bar
• max. temperature of the pumped medium: + 110 °C
• protection class: IP44, insulation class: FH
• material of pump parts: cast iron / plastic
• supply voltage: 230 V
• distance between suction and discharge nozzle: 180 mm
• electric motor power: 182 / 170 / 145 W
• delivery head: 8 m, max. flow rate: 115 l/min
• connection dimensions: 6/4“
