Three-speed circulation pump AVANSA 25-4/130

Product detailed description

- installation length 130 mm, displacement 4 m, max. flow 48 l/min

Applicable in systems for hot and cold non-potable water. The pump body is made of cast iron, cast aluminium. A high-quality bipolar motor, asynchronous, does not require overload protection, has three speeds. It is controlled by a special switch mounted on the terminal block, which allows the pump to be adjusted to the characteristics of the device.

Technical data:

• max. working pressure: up to 10 bar
• max. temperature of the pumped medium: + 110 °C
• protection class: IP44, insulation class: FH
• material of the pump part: cast iron / plastic
• version: 230 V
• distance between suction and discharge nozzle: 130 mm
• electric motor power: 72 / 53 / 38 W
• displacement 4 m
• max. flow: 48 l/min
• connection dimensions: 6/4“
