Electronic circulation pump DAB EVOSTA3 60

Product detailed description

Single-phase electronic circulation pumps EVOSTA3 with permanent magnet synchronous motor and frequency inverter intended for heating systems.

• low energy consumption (min. 3W)
• easy installation and setup
• unblocking and air venting of the pump via the front plug
• integrated connector without the need to open the terminal box
• display showing the pump's operating status
• protection class IP X5 prevents water ingress
• delivery including thermal insulation of the pump housing

The EVOSTA3 circulation pump series ensures high efficiency in all applications and brings significant energy savings. The pump contains an electronic device for detecting pressure changes in the system and automatically adjusts the power, ensuring maximum efficiency with minimal energy consumption.
All models have a vent plug and allow manual release of the motor shaft. The cast iron body has cathodic coating, the housing is made of stainless steel. Waterproof electronics with protection class IPX5.
EVOSTA3 has a display for showing the selected operating mode, speed level, instantaneous power consumption, instantaneous head and flow. Thanks to the new EVOSTA3 standard connector, it is interchangeable with connectors of other brands without the need for new electrical connections.

Technical data:

• operating range: from 0.4 to 3.6 m³/h
• operating pressure up to 10 bar
• power supply: 230 V / 50/60 Hz
• max. head: 6 m
• pump connection: 6/4“
• construction length: 130 mm and 180 mm
• max. temperature: 120 °C
• operation options: constant pressure, proportional pressure, constant speed
• pumped liquid: clean without solid particles and mineral oils, without viscosity, chemically neutral with properties close to water (max. glycol content 30%)
