DHW cylinder Protherm FE 200 BM (floor-standing)
Code: 0010015965Product detailed description
- Indirectly heated tank with a spiral tubular heat exchanger
- Net volume of the tank 184 liters
- Steel tank with high-quality enamel
- Stationary version with adjustable feet for uneven surfaces
- Protection against corrosion magnesium anode
- Easy connection of the recirculation circuit
- Easy water draining from the tank via a built-in drain valve
- Improved cold water stratification at the bottom of the tank thanks to a new cold water inlet diffuser design
- Minimal heat losses thanks to a new type of PUR rigid foam insulation (energy class "B")
| Technical parameters: | B 60 Z | ||
| Energy class for hot water preparation | B | ||
| Volume of usable water [l] | 184 | ||
| Max. operating pressure [bar] | 10 | ||
| Max. water temperature [°C] | 85 | ||
| Max. heating water inlet temperature [°C] | 110 | ||
| Connection W | R 1" | ||
| Connection of usable water | R 3/4" | ||
| Recirculation connection | R 3/4" | ||
| Drain valve and plug | G 1" | ||
| Thermal power [kW] | 43,2 | ||
| Hourly flow rate [l] | 829 | ||
| Amount in 10 min. [l] | 279 | ||
| Energy losses in standby mode [kW/d] | 1,4 | ||
| Heating surface of the heat exchanger [m2] | 1 | ||
| Heating water content in the heat exchanger [l] | 6,8 | ||
| Pressure loss in the heat exchanger at max. heating water consumption [mbar] | 22 | ||
| Flow rate of heating water [l/h] | 1400 | ||
| Continuous performance of hot water at heating water temperature 85/65°C [kW] | 43 | ||
| Dimensions | |||
| Height / Diameter [mm] | 1174 / 590 | ||
| Weight with operating fill [kg] | 281 | ||
| Weight without water [kg] | 97 | ||
Additional parameters
| Category: | hot water cylinders |
|---|---|
| Warranty: | 2 years |
| Weight: | 79.2 kg |
