ATMOS DC 32 S

Code: DC32S

Sale Wholesale discount Wholesale discount 2

Not rated Rating details

Brand: ATMOS

–13 %

4 075,76 € –13 % 3 545,91 € / pcs 2 882,85 € excl. VAT

In stock at supplier

- 35kW ecological wood-burning boiler - DREVOPLYN with exhaust fan and cooling loop

Detailed information

Show all related products

Product detailed description

- 35kW ecological gasification boiler for wood - DREVOPLYN with exhaust fan and cooling loop

It is designed for wood combustion based on the principle of gasification using an exhaust fan (S), which draws off flue gases from the boiler.

The boiler body is made as a welded structure from high-quality steel sheets of thickness 3 to 8 mm. It includes a fuel hopper (6 mm thick), which is equipped with a gasification nozzle with a longitudinal opening for the passage of flue gases and gases at the bottom. The combustion chamber below it is equipped with ceramic refractory bricks for ideal combustion of all combustible substances with high efficiency and environmentally friendly combustion. At the rear part of the boiler body is a vertical flue gas channel, which is equipped with a firebox door at the top. The upper part of the flue gas channel is equipped with an exhaust collar for connection to a chimney.

Basic technical data of Atmos DC32S:

output: 35 kW
efficiency 88.9%
required chimney draft: 24 Pa
boiler weight: 366 kg
water volume: 80 L
fuel hopper capacity: 135 dm³
maximum wood length: 530 mm
prescribed fuel: dry wood with calorific value 15 – 18 MJ/kg, diameter 80 – 150 mm and moisture content 12 -20 %
minimum return water temperature: 65 °C
recommended connection ATMOS F2 Laddomat, ATMOS F4 ESBE
combustion class: 5
energy efficiency class: A+
control panel with standard regulation

Option to order left-opening door version available.
Please specify in the note when placing the order.

Note: This type of boiler is also available in version with built-in thermostat ACD04 with touch display ATMOS DC32S REG, or also in version with automatic ignition and electronic control AC32, boiler ATMOS DC32S ZAP

Advantages of wood gasification boilers ATMOS:

possibility to burn large pieces of wood
large fuel storage = long burning time
high efficiency
eco-friendly combustion - boiler according to CSN EN 303-5 classes 4 and 5, Ecodesign 2015/1189
exhaust fan - dust-free ash removal, smoke-free boiler room
cooling loop against overheating - no risk of boiler damage
automatic boiler shutdown after fuel burnout - flue gas thermostat
convenient ash removal - large ceramic combustion chamber for ash (with wood, ash is removed once a week)
boiler without boiler tubes - easier cleaning
small dimensions and low weight
high quality

Additional parameters

Category:	Atmos WOOD GASIFICATION
Warranty:	2 years
Weight:	420.9 kg

Show all alternative products

Product rating

Be the first who will post an article to this item!

Name

E-mail

Comment

How would you rate this product? Choose 1 to 5 stars, where 1 is the worst and 5 is the best rating.

By submitting a review, you agree to the privacy policy

Discussion

Samuel 07.01.2024 17:35

Zdravím, rád by som sa opýtal, kolko priemernych izieb v dome dokaze tato pec vykurit. dakujem

Zoli 02.09.2024 07:04

Ja s tymto kotlom vykurujem 220 m2, je to prenmo hracka…popritom mi zohrieva aj bojler, mala spotreba, mám moznost kurit aj s peletami… tento kotol je dobra volba.

Atmos is a Czech family company. Almost 100 years of history, progressive development and experience make it
one of the largest leading European manufacturers of solid fuel boilers today. It has a permanent presence in the Czech Republic
and Slovakia, while exporting most of its production abroad.

The range includes wood gasification boilers from 15 to 150 kW, gasification boilers for brown coal (and wood)
from 15 to 48 kW, gasification boilers for brown coal briquettes and hard coal with outputs of 16 and 26 kW, automatic pellet boilers from 4.5 to 80 kW and combination boilers for wood gasification combined with a pellet burner
with outputs from 20 to 35 kW.
Atmos products have attracted great interest among users and installation companies alike for their functionality, quality
and ease of installation and operation.

Through the Slovak Innovation and Energy Agency’s national projects Zelená domácnostiam (a Slovak subsidy programme), family houses and apartment buildings will be able to obtain support for installing small systems that use renewable energy sources. The support may only be used for equipment that meets the technical conditions and is registered.

Most ATMOS boiler types (marked with the logo) are eligible equipment, and you can apply for a subsidy. More information can be found HERE.
